Where the 2 Ton Electric Forklift Fits
Choose the HLCPD20-C for verified loads within the 2,000 kg rating at a 500 mm load centre when quiet operation and planned charging suit the site.
- Check the heaviest load and its dimensions.
- Compare the 2,280 mm turning radius with aisle and staging space.
- Confirm floor, ramps, travel distance and daily hours.
Mast, Load Centre and Attachment Check
Long loads, higher lift heights and hydraulic attachments can move the effective load centre and reduce usable capacity.
- Send maximum load weight and dimensions.
- State lift height and lowered mast clearance.
- Identify fork length, side-shifter, clamp or other attachment needs.
Battery and Charger Selection
The source specification lists a 60–72V / 210Ah lead-acid battery, with lithium optional. Battery and charger selection depends on shift length, charging windows, temperature and local power supply.
- Provide local voltage, frequency and plug requirement.
- State single-shift, multi-shift or opportunity-charging use.
- Confirm the final battery and charger in the quotation.
Export, Packing and Support
The quotation should identify battery, charger, mast, tyres, forks, attachments, packing, Incoterm, destination port, warranty scope and included documents. Keep model and serial information for later parts identification.
MOQConfirm with configuration
Lead TimeConfirm with configuration
Warranty12 months
CertificateAvailable on request
What is the rated capacity of the HLCPD20-C?
The rated capacity is 2,000 kg at a 500 mm load centre. Long loads, high lifts and attachments require a capacity check.
What battery does the HLCPD20-C use?
The source specification lists a 60–72V / 210Ah lead-acid battery, with lithium optional. Confirm the battery and charger for the intended shift and local power supply.
How much turning space does it require?
The published turning radius is 2,280 mm. The complete aisle check must also consider load length, pallet size, fork length and operating clearance.
Can a higher mast or attachment be quoted?
Compatible mast and attachment options can be reviewed after the load, lift height and application are confirmed. Their effect on capacity and dimensions must be checked.
What are the MOQ and lead time?
MOQ and lead time depend on battery, charger, mast, attachments, branding and quantity. They are confirmed in the configured quotation.
What information should the RFQ include?
Include load dimensions, load centre, lift height, aisle width, shift hours, charger input, attachments, quantity and destination port.
