Applications
Where the HLCPD40-B Fits
Heavy pallet handling
Factory material flow
Warehouse operations
Indoor loading areas
Buyer Guidance
Model Fit and Working Space
Choose this model when verified loads need the 4,000 kg class and the site can support its operating weight, turning space and charging plan.
- Send the heaviest load weight and dimensions.
- Confirm aisle or turning space with the load included.
- State lift height and lowered mast clearance.
Load Centre, Mast and Attachments
The nominal rating applies at the stated 500 mm load centre. Long loads, high lifts and attachments can reduce usable capacity.
- Provide load centre or centre-of-gravity information.
- Identify fork length and attachment requirements.
- Request a residual-capacity review for the final configuration.
Battery and Charger Configuration
The source specification lists a 15 kW AC drive and 60–72V / 300Ah lead-acid battery, with lithium optional. Battery sizing must follow shift hours, charging windows and temperature.
- Provide local voltage, frequency and plug.
- State shift hours and charging windows.
- Confirm battery and charger in the quotation.
Export, Packing and Support
The quotation should identify the complete machine configuration, packing method, Incoterm, destination port, warranty scope and included documents. Keep model and serial information for later parts support.
Model Comparison
Compare Related Models
Purchase & Export
Quotation Information
MOQConfirm with configuration
Lead TimeConfirm with configuration
Warranty12 months
CertificateAvailable on request
Include in your RFQ: model HLCPD40-B, load weight and dimensions, load centre, lift height, aisle width, floor and ramp conditions, shift hours, battery preference, charger input, attachments, quantity, destination country and port.
Buyer Questions
HLCPD40-B FAQ
What is the rated capacity of the HLCPD40-B?
The rated capacity is 4,000 kg at a 500 mm load centre. Residual capacity must be checked for long loads, high lifts and attachments.
What battery and drive system does it use?
The source specification lists a 15 kW AC drive and 60–72V / 300Ah lead-acid battery, with lithium optional.
What site information is important for a 4 ton electric forklift?
Provide floor capacity, gradients, turning space, load geometry, travel distance, shift hours and charging windows.
What are the MOQ and lead time?
MOQ and lead time depend on configuration, attachments, branding and quantity. They are confirmed in the model-specific quotation.
Can a higher mast or attachment be quoted?
Compatible options can be reviewed after the load and application are confirmed. Their effect on capacity and dimensions must be checked.
What information should the RFQ include?
Include load dimensions, load centre, lift height, working space, duty cycle, options, quantity and destination port.
